Description
This machine from SATRA’s extensive range replaces STD 409 and incorporates many features not found on that model, including motorized lift of the striker mechanism which moves automatically to a pre-set height and includes a speed sensor that will determine if the correct impact energy has been achieved.
A slide mechanism ensures minimum frictional losses and it also incorporates a belt drive system to provide the striker drop height position. The guarding provides complete operator safety while giving full access to the anvil area for ease of setting up each test. An antibounce device prevents a double impact strike on the footwear under test.
The machine is supplied as standard with all the anvils and strikers required.
The impact test rig is mounted on a secondary steel block weighing approximately one tonne. This block can be provided with the machine at additional cost or a drawing can be provided for local supply or manufacture.
Consumables:
- STM 611 Foil
- 304976 Modelling clay
